Grass Valley iControl V.4.43 - Manual (Page 515)

iControl
User Guide
505
2. Double-click an alarm to view its details.
Figure 8-114
Configuring iControl to Send Traps
Once an iControl GSM has been configured to act as an SNMP agent, all alarms in its database
can be polled by a third-party SNMP Manager. You can give special attention to individual
alarms (or combinations of alarms) by assigning SNMP traps. When these alarms change state,
they will send a trap, via the GSM, to the third-party SNMP Manager.
Assigning an SNMP Trap to One or More Alarms
To assign an SNMP trap to one or more alarms
1. In the GSM Alarm Browser, select the alarm(s) to which you would like to assign SNMP traps.
REQUIREMENTS
Make sure you meet the following conditions before beginning this procedure:
• You have opened iControl (see page 696 ).
• You have opened iC Navigator (see page 719 ).
• You have opened the GSM Alarm Browser (see "Opening the GSM Alarm Browser" , on
page 732).
Note: You can assign the same trap to more than one alarm by making a multiple
selection (Shift+Click or Ctrl+Click).
