Chapter 3 Using the Media Manager
94 Profile Family
An unconnected machine icon appears if no connection could be made
or if you cancel the connection in the Hardware Communication dialog
box. This icon cannot be expanded.
A non-Profile server that recognizes Media Manager connection
requests. Media may be copied to this server from other machines on the
Fibre Channel network.
The next icon is the volume. A machine’s storage is divided into one or
more volumes. The volume icon represents a physical set of disks—
either an internal disk set, and external expansion box (such as the
PDX208), or a RAID disk array (PRS200).
Below a volume icon are bin icons.
A Recycle bin appears below each volume.
A master.
Clips and archived clips with audio and video.
Clips and archived clips with no audio.
Clips and archived clips with no video.
The transit icon indicates a clip that is currently being copied to the bin from
another Profile unit or is being restored from the library. The state is only shown
for transactions initiated from the current Media Manager. The icon is updated
when the transfer is complete.
This icon is used when Media Manager does not recognize an item in the Profile
clip database, or if a transfer or archive operation is incomplete.
The library icon appears after volume icons. The library icon will only
appear on machines connected to a Profile library system. After
expanding a library icon,
The cartridge icon appears below the library icon.
The cleaning cartridge icon may appear anywhere in the list of
cartridges.
