Grass Valley PDR v.2.2 - Manual (Page 184)

Chapter 4 Using VdrPanel
166 Profile Family
Setting In and Out Marks in Clips
You can set a temporary beginning and ending to a clip by marking an in point,
an out point or both. The video and audio data is not lost, however: it simply is
not used when the clip is played. For example, if you set a mark-in point five
seconds into a clip, it plays at the five second mark instead of at the beginning,
but if you remove a mark-in, it returns the beginning of the clip to the actual
clip start.
NOTE: Setting in and out marks applies to Panel Control only. It is
not recommended for other protocols.
Setting Marks
To set a new in mark and out mark in a clip:
1. Click a panel to select it.
2. Create a clip, load a clip, or load a clip list and then select a clip from the list.
The Clip Position Bar is all the way to the left and the Timecode is
00:00:00:00.
3. Use the transport controls, drag the Clip Position Bar , or click on the
Timecode display to enter a timecode to locate the frame where you want to
set the in mark.
4. Click Set In Mark . The Timecode display remains the same, but the Clip
Position Bar jumps to the far left, indicating the mark-in point on the clip.
5. Use the transport controls, drag the Clip Position Bar , or click on the
Timecode display to enter a timecode to locate the frame where you want to
set the out mark.
6. Click Set Out Mark . The Timecode display remains the same, but the Clip
Position Bar jumps to the far right, indicating the mark-out point of the clip.
7. Drag the Clip Position Bar to the beginning of the clip.
8. Click Play . The clip starts at the in mark and stops at the out mark.
