Chapter 3 Using the Media Manager
110 Profile Family
- To inventory the cartridge, click Inventory the cartridge and update the
library . The cartridge is loaded into a transport and its contents are
inventoried. The database is updated if it did not match what was
inventoried.
- To import an unformatted cartridge, click Import unformatted cartridge .
The cartridge is put into the first available slot and appears in the media
tree with an unformatted cartridge icon.
- To import a new cleaning cartridge, click Import new cleaning
cartridge . The library system cannot differentiate between a cleaning
cartridge and an ordinary cartridge. It must be told when a cleaning
cartridge is imported. If you provide a unique tape label, the cleaning
cartridge is stored in a cleaning cartridge bin.
5. Click Import .
6. A prompt appears requesting that you physically insert the cartridge into the
library. Once the robot is in position and you insert the cartridge, press any
button on the library’s control panel.
7. The Importing Cartridge dialog box remains on the screen until the robot
puts the cartridge in the available slot. Since this is done in the background,
click
OK at any time.
When the robot retracts with the imported cartridge, it scans the cartridges’s
barcode. If the barcode does not match the name that was entered for the import,
it is rejected.
