Chapter 10 Using TimeDelay
272 Profile Family
Setting up Timecode
The Set Timecode dialog box enables you to set the timecode display and the
source on a channel to the values required for your application.
1. Click anywhere within the specific Panel dialog box to select the panel.
2. Select Options | Select Timecode to access the Timecode Setup dialog box.
The Timecode Setup dialog box is divided into two groups: Display on Panel
and Timecode Generator Settings .
Figure 144. Timecode Setup dialog box
3. Select the timecode to be displayed on the panel from the Display on Panel
group:
- LTC Input is a separate signal input to the disk recorder via the genlock
card.
- VITC Input is the timecode from the VITC input signal. It may be part of
the video signal being recorded.
- Compute from Field Number calculates the timecode directly from the
field number of the recorded video. New clips start at 00:00:00:00.
- TC Rec # displays the recorded timecode.
- Generator displays the timecode from the generator for the channel.
