Chapter 10 Using TimeDelay
294
Profile Family
JoinPrevious
JoinPrevious panel
Combines the selected segment with the previous one in the list of segments.
Valid for censor channel only; ignored for record and playback channels.
UI equivalent:
Clicking on the
Join Prev
button.
Packet format:
41 41 pa cs
where:
pa = panel
cs = checksum
Lockout
Lockout
The first time this command is sent, it activates the Lockout dialog box in the
TimeDelay UI, which prevents using the UI. The next time the command is
sent, it removes the dialog box, thereby removing the lock.
UI equivalent:
File | Lockout Panel
Packet format:
60 36 cs
where:
cs = checksum
NOTE: No password is required for remote control, however, the
command to disengage the lock must be sent from the same port as the
original lockout command.
MarkIn
MarkIn panel
Sets the in point for the current clip. Valid for censor channel only; ignored for
record and playback channels.
UI equivalent:
Clicking on the
button.
Packet format:
31 36 pa cs
where:
pa = panel
cs = checksum
