Chapter 10 Using TimeDelay
266 Profile Family
Configuring the Panels
Click anywhere within the specific Panel dialog box to select the panel. The
title bar is highlighted when a panel is selected. The following options are
available from the Controller menu:
• Select sets u p the panel as Panel Control or Remote Control.
• Configure sets the playback and record JPEG channels, audio channels and
the VITC timecodes.
• Comm Port assigns the communications port to use if remote control is
selected.
Selecting a Controller
To select a controller:
1. Click anywhere within the specific Panel dialog box to select the panel.
2. Select Controller | Select to access a Controller Setup dialog box.
Figure 139. Controller Setup dialog box
3. Select the type of control for the channel and click OK .
- Panel Control specifies control from the Windows NT user interface. No
communication port selection or configuration is necessary.
- Remote Control specifies control via the RS-422 interface. This option
requires the additional configuration and communication port set up.
