Chapter 8 Using the Tool Box Editor
196 Profile Family
4. Choose a video input from the Video Input check boxes. The default is the
first video input. The number and names of video inputs are determined by
the system configuration created with Configuration Manager. You can
choose only one video input at a time per channel.
5. Now choose a video output. The default is the first video output. The number
and names of video outputs are determined by the system configuration
created with Configuration Manager. You can choose one or more video
outputs at a time. Each output corresponds to one of the video output
connectors on the back of the Profile. Once allocated, other Profile channels
cannot share assigned video outputs.
6. Click on the More button to set field dominance and still-play mode:
• Field dominance determines which field is the mark-in or mark-out point for
the frame. The default is Field 1. To set it to Field 2, click on the button.
• Still-play mode determines whether your still frames are interlaced or line-
doubled. Line-double is the default. With interlaced, you may get some
flicker in still display. Line double reduces flicker.
Configuring Audio Resources
Click on the Audio icon to select audio channels. The default is the first two
audio channels (Channels 1 and 2). To choose audio channels, click on the
check box for the desired channels (1–16). Once allocated, other Profile
channels cannot share the assigned audio channels. For example, if Channel A
has all 16 audio channels, these audio channels cannot be shared with Channels
B, C or D.
