Performing PFR500 maintenance tasks
23 July 2004 Profile XP System Guide 101
3. Click Open. The Progress Report window appears showing the disk firmware
download task and the percentage completion. (Disk access LED behavior:
flashing green during download; off during disk reboot; flashing green during disk
initialization.)
NOTE: If you receive a warning that some disks failed to download, make note of
the disk numbers, then proceed to “Disk firmware download: Alternate procedure”
on page 101 to recover from this condition and complete the firmware upgrade.
4. Perform step 1 through step 3 to upgrade disk drives for the remaining controllers.
5. After successfully downloading disk firmware, use the following steps to restore
default disk settings. This is required after downloading disk firmware.
a. Right-click the controller in the tree view, then select Restore Disk Settings in
the context menu. The hour glass appears while the operation is performed. This
takes several seconds.
b. On receiving “Operation Successful” message, click OK .
c. Repeat step a and step b for remaining controllers.
6. Reboot the RAID storage and the Profile XP media platform using the “System
reboot procedure” on page 94.
NOTE: If your PFR500 is part of an Open SAN, disregard the previous step, and
refer to the instructions in the Open SAN Instruction Manual for powering-off and
powering-on the Open SAN.
This concludes the Loading Disk Firmware procedure.
Disk firmware download: Alternate procedure
NOTE: Perform this procedure only when you receive a warning that some disks
failed to download while performing the procedure “Downloading PFR500 disk
drive firmware” on page 100.
In some cases, rebooting the PFR500 RAID Controller chassis results in successful disk
firmware upgrades for disks that report a download error. If disks still fail to upgrade,
you can download firmware to a single disk. After all disk are upgraded, you must
restore disk settings.
To upgrade firmware for remaining disks and restore disk settings:
1. Reboot the RAID storage and Profile XP media platform using the “System reboot
procedure” on page 94.
NOTE: If your PFR500 is part of an Open SAN, disregard the previous step, and
refer to the instructions in the Open SAN Instruction Manual for powering-off and
powering-on the Open SAN.
2. Use the following steps to verify the firmware version on all disks:
a. In the GVG Disk Utility, select a disk icon, and note the drive firmware version,
the repeat for all disk drives.
