Profile XP System Power Specifications
23 July 2004 Profile XP System Guide 317
Profile XP System Power Specifications
Profile XP system power specifications are shown in the following table.
PAC 216 Power Requirements
The following table lists the power requirements for the PAC216 audio chassis.
Characteristics Safety Rating Supplemental Data
Mains Voltage Steady
State Amplitude 100-240V
RMS
87-264 V
RMS
Mains Frequency
Range 60-50Hz 47-63Hz
Mains Steady State
Current
a
7A max @100 V
RMS
3A max@240 V
RMS
5A max @120 V
RMS
Mains Inrush Current a
a.
Per power supply.
70A @240 V
RMS
, max
35A @120 V
RMS
, max
Supply Type Single Phase
Supply Connection Detachable cord set
(IEC320 filtered inlet connector)
Efficiency >70%
Power Output Rating 430 W maximum
Thermal Output 2100BTU/h max
(assuming max configuration)
Characteristic Specification
Voltages/current from power supply +5V, 1.9 A maximum
Typical Total Power 9.0 Watts typical
Maximum Heat Dissipation 32.42 BTU/hour (9.5 watts)
