Setting up the VITC reader on the Reference Input
23 July 2004 Profile XP System Guide 223
Setting up the VITC reader on the Reference Input
The VITC reader has two detection modes: Automatic and Manual. When you select
automatic detection, you can set the range of vertical interval lines scanned to find the
VITC signal pair; lines 10 to 21 by default. Manual allows you to choose specific line
numbers to detect the VITC signals. Automatic detection is the default setting. Use
automatic detection unless there are two sets of VITC on the input signal.
To set up the Reference Input VITC reader:
1. Select Video Timing in the Configuration Manager window. The Video Timing
dialog box appears.
2. Click Next to navigate to Video Timing page 3 of 3.
