Checking AES/EBU input status
23 July 2004 Profile XP System Guide 203
Checking AES/EBU input status
The Audio Input dialog box in Configuration Manager allows you to check AES/EBU
input status.
To view AES/EBU input status:
1. Click Audio Input in Configuration Manager. The Audio Input dialog box appears.
2. Click Next to navigate to Audio Input page 2.
3. Select the AES/EBU pair. The following signal status is shown:
4. Click Finish or Cancel .
Indicator Description
Unlocked Error receiver locked
Validity Error AES receiver validity
Parity Error parity error
CRC CRC subframe errors
Emphasis detected emphasis
