Rear Panel Drawings
Profile XP Media Platform Chassis
XLR 216 and BNC 216 AES/EBU Breakout Panels
8112-1
Profile XP Media Platform
Video I/O,
VideoOut, or
Video Monitor
LTC/
GPI Video
network (opt.)
FC Disk (Port A)
FC Disk
(Port B)
Audio
Channels
1-16 (opt.)
SDTI
(opt.) Audio
Channels
1-16
Optional
Power
Supply
Power Cord
Power
Good LED
Reference In
(Loop-Thru)
RS-422
Breakout
Mouse
Keyboard
Com1 (RS-232)
Monitor
Parallel Port
Ethernet
(Windows NT
Network)
0624-8
BNC216 (rear mounted)
In Out
. . .
1/2 1/2
Mon
Out
Digital (AES/EBU)
1-16
AES
Ref
XLR216 (rear mounted)
Connector 1/2 Audio I/O
In
Out
Digital (AES/EBU)
1-16
AES
Ref Spares
AES/EBU
Monitor
Push Push Push Push Push Push Push Push Push Push Push Push Push Push
Connector 1
PAC
Breakout
