SMA SUNNY HOME MANAGER User Manual
Page 37
SMA Solar Technology AG
6 Page and Menu Selection
User Manual
HoMan_Portal-BA-en-17
37
Day
• With selected view Stacking order (
):
The lines below in the diagram show the progression of the power drawn
by each load on the selected day. Using the legend below the diagram,
you can show and hide the loads displayed in the diagram and change
the stacking order of the loads in the diagram (see Section 7.3,
page 51).
• With selected view Time period (
):
The light-colored bars show the time periods which you have configured
for the operation of the load.
The dark-colored bars show the time periods for which the loads were
actually in operation.
– The symbols ▸ and ■ show the start and the stop point of operation.
– If you move the mouse pointer over one of the dark-colored bars, the
energy consumed by the load in this time period is displayed in kWh.
• In the table:
Daily consumption: Energy drawn by the load on the selected day
Configuration: With the Configuration button [
] you can
configure the properties of the load.
Month
• In the diagram: Energy drawn by each load in the selected month in days
If you move the mouse pointer over one of the bars in the diagram, a
window opens with the following information:
– The respective daily consumption of the loads operated on that day
– The respective percentage of the daily consumption which was
covered by PV energy ( ), battery discharging ( ) or by the utility
grid ( )
• In the table:
Monthly consumption: Energy drawn by the load in the selected
month
PV energy percentage: Percentage of the monthly consumption
covered by PV energy
Battery discharging percentage: Percentage of the monthly
consumption covered by battery discharging
Purchased electricity percentage: Percentage of the monthly
consumption covered by the utility grid
Configuration: With the Configuration button [
] you can
configure the properties of the load.
Tab
Content
