 User-definable module data memory mapping of thousands of DNP3 Ethernet points
based on the various types of data.
DNP 3.0
Ethernet Data
Point Type
Range
DNP_Outputs
Binary Outputs 0 to 8000 points (500 16-bit words)
16-bit Analog Outputs 0 to 5000 points (if all other DNP Outputs are 0)
32-bit Analog Outputs 0 to 2500 points (if all other DNP Outputs are 0)
Float Outputs 0 to 2500 points (if all other DNP Outputs are 0)
Double Float Outputs 0 to 1250 points (if all other DNP Outputs are 0)
DNP_Inputs
Binary Inputs 0 to 8000 points (‘500’ 16 -bit words)
16-bit Analog Inputs 0 to 5000 points (if all other DNP Inputs are 0)
32-bit Analog Inputs 0 to 2500 points (if all other DNP Inputs are 0)
Float Inputs 0 to 2500 points (if all other DNP Inputs are 0)
Double Float Inputs 0 to 1250 points (if all other DNP Inputs are 0)
Counters 0 to 1000 points
IED_Outputs
Binary Outputs 0 to 8000 points (500 16-bit words)
16-bit Analog Outputs 0 to 20000 points (if all other IED Outputs are 0)
32-bit Analog Outputs 0 to 10000 points (if all other IED Outputs are 0)
Float Outputs 0 to 10000 points (if all other IED Outputs are 0)
IED_Inputs
Binary Inputs 0 to 8000 points (‘500’ 16 -bit words)
16-bit Analog Inputs 0 to 20000 points (if all other IED Inputs are 0)
32-bit Analog Inputs 0 to 10000 points (if all other IED Inputs are 0)
Float Inputs 0 to 10000 points (if all other IED Inputs are 0)
Counters 0 to 1000 points
Binary Output Status 0 to 8000 points (‘500’ 16 -bit words)
16-bit Analog Output Status 0 to 20000 points
32-bit Analog Output Status 0 to 10000 points
Float Output Status 0 to 10000 points
4.1.2 Functional Specifications
TheMVI56E-DNPNET operates on a Local or Remote rack CIPconnect ® enabled for module
and network configuration using 1756-ENxT module with EtherNet/IP pass-through
communications.

4-digit LED Display for status and diagnostics information
 Error codes, network error counters, and port status data available in user data memory
Server Specifications
The DNP3 Ethernet port can accept DNP3 Ethernet commands to control and monitor data
stored in the module’s DNP3 Ethernet server database. If a DNP3 Ethernet Client is also
configured, a portion of the server database can be derived from or can control IED devices
connected to the DNP3 Ethernet Client.
