3-8 Installation
DCT5100 Installation Manual
Audio-Only Receiver
When connecting to an audio-only receiver, such as a home mini system, follow a daisy-chain
convention. Figure 3-6 illustrates how the audio and video paths flow through each device in a
daisy-chain fashion:
Figure 3-6
Audio-only receiver
Stereo
receiver
AUDIO OUT
R
AUDIO IN
L
SPEAKER
CONNECTORS
DIGITAL INPUT
COAX
OPTICAL
ETHERNET
USB
HPNA
AUDIO IN
AUDIO
OUT
VIDEO
IR
R IN
R
L OUT
S-VIDEO
IEEE 1394
OPTICAL
SPDIF
SPDIF
L Y Pb Pr
TV
Pass Card
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
CONVENIENCE
OUTLET
TO
TV/VCR
CABLE
IN
DCT 5100
TV
either/or
CD player
AUDIO OUT
L R
CABLE
IN
INPUT OUTPUT
VIDEO VIDEO AUDIO AUDIO
L L R R
S-VIDEO S-VIDEO
VCR
To TV
CABLE/
ANTENNA IN
INPUT
VIDEO AUDIO
L R
S-VIDEO
OUTPUT
VIDEO AUDIO
L R
S-VIDEO
From
cable outlet
