4-12 Diagnostics
DCT5100 Installation Manual
MODE
Table 4-13 lists the values for the MODE display on the OSD:
Table 4-13
MODE values - OSD
Value Description
ANALOG IB Contains an Analog channel
64 QAM IB Contains a Digital channel with a modulation mode of 64 QAM
256 QAM IB Contains a Digital channel with a modulation mode of 256 QAM
CARRIER LOCK
The IB CARRIER LOCK indicates if the IB receiver is locked to the carrier.
Table 5-15 illustrates valid values displayed on the LED and OSD:
Table 4-14
In-Band CARRIER LOCK - OSD and LED
OSD Display LED Display Definition
YES L Carrier locked
NO U Carrier unlocked
DATA
The IB data indicates if data is being carried on the IB stream. The indicators cover all packet
processors regardless of which stream they are monitoring.
Valid values for the OSD and LED are illustrated in Table 4-15:
Table 4-15
In-Band DATA indicators – OSD and LED
OSD Display LED Indicator Definition
YES on IB Data detected within last 5 seconds
NO off IB Data not detected within last 5 seconds
