Diagnostics 4-35
DCT5100 Installation Manual
UPM
The UPM is the upstream modem address. The value used for the UPM is the same as the
terminal ID assigned by the DAC 6000. The UPM is a unique, system-generated, eight-digit
integer between 1 and 16777215.
00000000 is displayed when the UPM is not configured or unknown.
UPSTREAM ID
The UPSTREAM ID is a set-top transmission parameter assigned by the DAC 6000 for the
interactive set-top. The UPSTREAM ID is a four-digit decimal value ranging from 0000 to 9999.
0000 is displayed if the UPSTREAM ID is not configured or unknown.
DOWNSTREAM ID
The DOWNSTREAM ID is a set-top transmission parameter assigned by the DAC 6000 for the
interactive set-top. The DOWNSTREAM ID is a four-digit decimal value ranging from 0000 to
9999.
0000 is displayed if the DOWNSTREAM ID is not configured or unknown.
STATE
The STATE parameter indicates the interactive status of the set-top:
LED OSD State Description
U UNCONFIG Set-top is not configured for the interactive system and
platform should run as Pre-Interactive.
C MAC_CONNECT Set-top is waiting to establish connection to MAC Pid Stream.
I dc INIT_WAIT_DC_OR_C Set-top is running in the interactive initialization state and
waiting for the default configuration or the contention channel
list messages.
I L WAIT_LM_ACK Set-top is running in the interactive initialization state and
waiting for Link Management Response ACK for Local
Address Message.
I SO WAIT_SO_ACK Set-top is running in the interactive initialization state and
waiting for a Sign On acknowledgement.
I LA WAIT_LA_OR_SO Set-top is running in the interactive initialization state and
waiting for Logical Address or Sign On with verification
Frequency message.
S I INIT_STOPPED Set-top is in the interactive initialization state and the
TransMode has stopped.
r dc RUN_WAIT_DC_OR_C Set-top is running in the interactive state and waiting for the
default configuration or the contention channel list messages.
r RUNNING Set-top interactive state is running, sending idle messages,
and waiting for any Prepare for Poll or MAC messages.
S RUN_STOPPED Set-top interactive run state has stopped and set-top is
waiting for status or transmission control message.
00 INVALID Set-top interactive state is unknown or invalid.
