4-14 Diagnostics
DCT5100 Installation Manual
d05 Unit Address
The UNIT ADDRESS diagnostic displays the unit address of the DCT5100.
Table 4-18 illustrates a unit address on OSD:
Table 4-18
UNIT ADDRESS - OSD
UNIT ADDRESS
TVPC INSTALLED NO
UNIT ADDRESS:
123-45678-90123-456
NETWORK ADDRESS:
123-45678-90123-456
OOB MULTICAST 16 ADDRESS FOR: nnnn
0123 4567
89AB CDEF
MAC Address 1– DOCSIS: xx xx xx xx xx xx
MAC ADDRESS 2 –
ETHERNET: xx xx xx xx xx xx
MAC ADDRESS 3 – 1394: xx xx xx xx xx xx
MAC ADDRESS 4 – USB: xx xx xx xx xx xx
MAC ADDRESS 5 – SET-TOP: xx xx xx xx xx xx
The value nnnn represents the following datastreams: DATA, POLL, NET, EMM, SCC, and
DWLD. The information on the OSD and LED updates every 5 seconds while the diagnostic
displays. After each OSD update, the six datastreams cycle and a different datastream (nnnn)
value with Multicast 16 Addresses is displayed.
TVPC INSTALLED
TVPC is a type of renewable security system. This diagnostic indicates if the renewable security
system is installed and the type. The OSD displays
YES if the TvPC is installed and NO if the
TvPC is not installed.
