4-32 Diagnostics
DCT5100 Installation Manual
OSD Display Definition
MAGENTA Magenta Foreground.
CYAN Cyan Foreground.
FOREGROUND OPACITY
Displays the FOREGROUND OPACITY option selected by the user:
OSD Display Definition
AUTO Foreground Color is controlled by the Closed Caption
stream.
TRANSPARENT Transparent Foreground Opacity.
TRANSLUCENT Translucent Foreground Opacity.
SOLID Solid Foreground Opacity.
FLASHING Flashing Foreground Opacity.
BACKGROUND COLOR
Displays the BACKGROUND COLOR option selected by the user:
OSD Display Definition
AUTO Background Color is controlled by the Closed Caption
stream.
WHITE White Background.
BLACK Black Background.
RED Red Background.
GREEN Green Background.
BLUE Blue Background.
YELLOW Yellow Background.
MAGENTA Magenta Background.
CYAN Cyan Background.
BACKGROUND OPACITY
Displays the BACKGROUND OPACITY option selected by the user:
OSD Display Definition
AUTO Background Color is controlled by the Closed Caption
stream.
TRANSPARENT Transparent Background Opacity.
TRANSLUCENT Translucent Background Opacity.
SOLID Solid Background Opacity.
FLASHING Flashing Background Opacity.
