Diagnostics 4-33

DCT5100 Installation Manual

SERVICE SELECTION

Displays the SERVICE SELECTION selected by the user:

OSD Display

Definition

AUTO

Service Selection is controlled by the Closed Caption
stream.

PRIMARY
LANGUAGE

Primary language established by the provider.

SECONDARY
LANGUAGE

Secondary language established by the provider.

3

Set by the provider.

4

Set by the provider.

5

Set by the provider.

6

Set by the provider.

SETTINGS

Displays the SETTING selected by the user:

OSD Display

Definition

AUTO

Closed Caption settings are determined by the closed
caption stream regardless of user modification.

USER

Closed Caption user settings are used as configured by
the user.

ASPECT RATIO Mode

Displays the ASPECT RATIO conversion mode selected by the user. The aspect ratio conversion
mode is the width-to-height ratio of your screen.

OSD Display

Definition

LETTERBOX

Letterbox

PAN-SCAN

Pan and Scan

CROPPED

Cropped, fixed Pan and Scan.
