3-14 Installation
DCT5100 Installation Manual
Boot Cycle
After connecting the proper cabling to the DCT5100, plug the power cord into the DCT5100 and
electrical wall outlet. Begin performing the boot cycle procedure:
The LED displays
HUNT and then FR 1 .
The DCT5100 begins searching for the headend Out of Band (OOB) frequency carrier. If the
OOB frequency is not set to 75.25 MHz, the LED flashes FR 1 and then flashes FR 2 . This
searching process repeats until the correct OOB frequency is found and the required
message for your set-top model is acquired. Table 3-1 illustrates the LED displays and OOB
frequencies:
Table 3-1
LED displays OOB frequencies
Display Frequency Description
| dl N/A OOB network download in progress
EF N/A Erasing Flash memory
FP N/A Flash memory is being programmed
____ N/A Network download complete
Hunt N/A Hunting for OOB frequency
FR 1 75.25 MHz Attempting to lock on frequency 1
FR 2 104.20 MHz Attempting to lock on frequency 2
FR 3 72.75 MHz Attempting to lock on frequency 3
FR 4 92.25 MHz Attempting to lock on frequency 4
FR 5 98.25 MHz Attempting to lock on frequency 5
FR 6 103.75 MHz Attempting to lock on frequency 6
FR 7 107.25 MHz Attempting to lock on frequency 7
FR 8 107.40 MHz Attempting to lock on frequency 8
FR 9 110.25 MHz Attempting to lock on frequency 9
FR 10 116.25 MHz Attempting to lock on frequency 10
Au N/A Authenticating code object (displays
only after download)
When the correct OOB frequency is acquired, the LED flashes
FR number.
