4-26 Diagnostics
DCT5100 Installation Manual
BOOTLOADER
The BOOTLOADER version is displayed in ASCII and includes major and minor revision
numbers.
DIGITAL SECURE PROCESSOR
The Digital Secure Processor version is displayed in ASCII format.
ANALOG SECURE PROCESSOR
The Analog Secure Processor version is displayed in ASCII format.
Downloadable Object Information Table
This table is displayed at the bottom of the OSD screen. It includes the object name, version
number, status of object and segments remaining in download process or total time of completed
download. The information displayed for each object depends on the running environment.
OBJECT NAME / VERSION
The OBJECT NAME and VERSION columns contain the names and versions of all objects
loaded, or in the process of being loaded into the set-top. The OBJECT NAME and VERSION
are displayed in ASCII format. If a download is not in progress, the LED displays the
environment currently running and version number as shown in Figure 5-9. On the LED
display,
bPC is displayed to represent base platform or Thin Client code.
STATUS
The STATUS associated with each object is displayed. The status value of nnnnnnnnnnnn is
replaced with the status of the object. The information on the OSD and LED is updated every
5 seconds while the diagnostic is displayed.
Table 4-32 lists the object status values:
Table 4-32
Object STATUS
OSD Display Status Description
MEM ALLOC Allocated Memory for object has been allocated.
LOADING Loading Object is currently being loaded.
STARTING Enabling Object is in the process of being started (the
constructor is running).
ENABLED Enabled Object is running.
ENA–NOT RUN Enabled_Not_Runnable Object has been enabled, but it is not runnable.
STOPPING Disabling Object is in the process of being stopped (the
destructor is running).
DISABLED Disabled Object has been disabled.
DIS-NOT RUN Disabled_Not_Runnable Object has been disabled, and it is not runnable.
