Diagnostics 4-7
DCT5100 Installation Manual
d03 Out-Of-Band (OOB) Diagnostic
The Out-of-Band (OOB) DIAGNOSTIC indicates the status of the out-of-band control channel.
The information is updated every 5 seconds while viewing the diagnostic.
Table 4-6 illustrates the OOB status on the OSD:
Table 4-6
OOB status - OSD
OOB DIAGNOSTIC
OOB FREQUENCY: 075.25 MHz
CARRIER LOCK: YES
DATA: YES
EMM DATA: YES
SNR: 22.1 dB GOOD
AGC: 23 % FAIR
NETWORK PID: 100C
EMM PID: 1003
EMM PROVIDER ID: 100A
