:SOURce:PHASe Commands
[:SOURce[<n>]]:PHASe[:ADJust]
Syntax
[:SOURce[<n>]]:PHASe[:ADJust] {<phase>|MINimum|MAXimum}
[:SOURce[<n>]]:PHASe[:ADJust]? [MINimum|MAXimum]
Description
Set the waveform start phase (basic waveforms and arbitrary waveform) of the
specified channel.
Query the waveform start phase (basic waveforms and arbitrary waveform) of the
specified channel.
Parameter
Name
Type
Range
Default
[<n>]
Discrete
1|2
1
<phase>
Real
0° to 360°
0°
Explanation
When [:SOURce[<n>]] or [<n>] is omitted, the system sets the related
parameters of CH1 by default.
If the start phase value in the command is lower than the corresponding start
phase lower limit, the system sets the waveform start phase of the specified
channel to the start phase lower limit.
Return Format
The query returns the waveform start phase in scientific notation with 7 effective
digits, for example, 1.000000E+01 (the waveform start phase is 10°).
Example
:SOUR1:PHAS 10 /*Set the waveform start phase of CH1 to 10°*/
:SOUR1:PHAS? /*Query the waveform start phase of CH1 and the query
returns 1.000000E+01*/
[:SOURce[<n>]]:PHASe:INITiate
[:SOURce[<n>]]:PHASe:SYNChronize
Syntax
[:SOURce[<n>]]:PHASe:INITiate
[:SOURce[<n>]]:PHASe:SYNChronize
Description
Execute an align phase operation in the specified channel.
Parameter
Name
Type
Range
Default
[<n>]
Discrete
1|2
1
Explanation
DG1000Z series dual-channel function/arbitrary waveform generator provides
the align phase function. After the align phase operation, the instrument
re-configures the two channels to make them output according to the
specified frequency and phase.
When [:SOURce[<n>]] or [<n>] is omitted, the system sets the related
parameters of CH1 by default.
When any of the two channel is in the modulation mode
), the align phase operation is invalid.
Syntax
:SOUR1:PHAS:INIT /*Execute an align phase operation in CH1*/
:SOUR2:PHAS:SYNC /*Execute an align phase operation in CH2*/
Related
Command
