Chapter 2 Command System RIGOL
DG1000Z Programming Guide 2-87
[:SOURce[<n>]]:BURSt:TDELay
Syntax [:SOURce[<n>]]:BURSt:TDELay {<delay>|MINimum|MAXimum}
[:SOURce[<n>]]:BURSt:TDELay? [MINimum|MAXimum]
Description Set the burst delay of the N cycle burst or infinite burst of the specified channel.
Query the burst delay of the N cycle burst or infinite burst of the specified channel.
Parameter Name Type Range Default
[<n>] Discrete 1|2 1
<delay> Real
Refer to the
“Explanation”
0s
Explanation  The burst delay is only applicable to the N cycle burst and infinite burst modes
( [:SOURce[<n>]]:BURSt:MODE ) and it refers to the time from when the signal
generator receives the trigger signal to when the instrument begins to output the
N cycle burst or infinite burst.
 For the N cycle burst or infinite burst in the external trigger or manual trigger
mode ( [:SOURce[<n>]]:BURSt:TRIGger:SOURce ), the range of <delay> is 0s to
100s.
 For the N cycle burst in the internal trigger mode, the range of <delay> is 0s to
(
2us
− × −
cycle waveform burst
N P P
) and it should be equal to or lower than 100s.
Wherein,
burst
P —— burst period;
waveform
P
——waveform period (namely the period of the burst function (such as
sine and square));
cycle
N —— number of the cycles of burst.
 When [:SOURce[<n>]] or [<n>] is omitted, the system sets the related
parameters of CH1 by default.
Return Format The query returns the burst delay in scientific notation with 7 effective digits, for
example, 1.000000E-01 (the burst delay is 0.1s).
Example :SOUR1:BURS:TDEL 0.1 /*Set the burst delay of the N cycle burst or infinite burst
of CH1 to 0.1s*/
:SOUR1:BURS:TDEL? /*Query the burst delay of the N cycle burst or infinite
burst of CH1 and the query returns 1.000000E-01*/
Related
Commands
[:SOURce[<n>]]:BURSt:MODE
[:SOURce[<n>]]:BURSt:TRIGger:SOURce
