9
2
Click [Network and Sharing Center].
3
Click [Change adapter settings].
4
Right-click the local area connection icon and then
click [Properties].
The properties window of the local area connection
appears.
5
Double-click [Internet Protocol Version 4 (TCP/
IPv4)].
The internet protocol (TCP/IP) properties window
appears.
6
Click [Use the following IP address], and then enter
the IP address in the IP address field.
Make sure not to use an IP address that is already
assigned to another device on the network.
7
Enter the subnet mask into the subnet mask field.
If you configure a value other than “255 255 255 0,”
the search for the receiver on the network will take a
long time.
8
Click [OK] to close the internet protocol (TCP/IP)
properties window.
9
Click [Close] to close the local area connection
properties window.
Connecting to the Network
Use straight LAN cables to connect the receivers,
RMU-01, battery chargers, and computer via a hub. When
the network connection is correctly made, the LED on the
LAN connector area at the rear of the receiver lights up
green.
Connect the devices required for system operation to the
rear panel of the receiver.
For details on connecting devices, refer to the Operating
Instructions supplied with the receiver.
• If the LED on the LAN connector area at the rear of the
receiver does not light up green, check the connection.
• For connections, use a category 5 or superior LAN cable
with a maximum length of 100 m (330 ft). If the
connection requires a total cable length exceeding 100 m
(330 ft), use a hub between the PC and the device.
• Use the cross cables when directly connecting the PC
and the devices.
• Do not touch the LAN connector directly with your
hands. The transfer of static electricity may result in
malfunction of the unit. As static electricity can
discharge from your body and clothes, be sure to remove
any static electricity before connecting or disconnecting
the LAN cable.
Note
Note
Notes
Receiver
RMU-01
Hub
PC
Battery charger
