MBT-5003 L-Band Up/Down Converter System
Revision 1
Front Panel Operation
MN-MBT5003
5–5
5.3
SELECT: (Main) Menu
SELECT: Config Monitor
Info Utility Test
Figure 5-2 illustrates the hierarchal structure of the SELECT: (Main) menu tree. The converter
commands are in a tree structured menu format designed for access and execution of all control
functions, and to prevent the execution of an invalid entry by the operator.
Figure 5-2. MBT-5003 Principal Menu Tree
