7. Technical Details
Physical Specifications
Physical Specifications
The following table provides physical specifications for the NV7512.
Specification Detail
Dimensions 14RU (24.5 inches, 622 mm) high
19.0 inches (483 mm) wide
18.0 inches (457 mm) deep
Weight 102 lbs (46.2 kg); 167 lbs (75.9 kg) fully loaded
Mounting EIA 310-C, 19.0 inches (483 mm)
Grounding terminal Copper, accepts 14-6 AWG
Modules and Module Slots 16 Input cards, up to 32 signals each
16 Output cards, up to 32 signals each
4 Crosspoint cards
2 Control cards (1 primary, 1 optional secondary)
1 Monitor card
3 Fan modules
Diagnostic Type: Serial port
Standard: SMPTE 207M, EIA-422/EIA-232, configurable
Connector: 2, DE9
Serial Control Type: Serial port (2 per control card)
Standard: SMPTE 207M, EIA-422
Connector: 4, DE9
Ethernet Type: 10/100 Base T
Standard: IEEE 802.3
Protocol: NVISION Ethernet protocol
Connector: 2, RJ45
GSC Node Bus Control Type: Serial
Standard: Proprietary
Connector: 2, BNC, loop-thru, non-terminating pair
Impedance: 75
Ω
Output Signal Monitor Type: Digital audio and AESid
Standard: See related section of this specification for standard for each
monitored signal type.
Connector: BNC or Phoenix
Impedance: 75
Ω or 110Ω
Signal Details: See related section of this specification for details for each
monitored signal type, I/O levels and return loss.
I/O Expansion Type: 10Base2 port
Standard: See related section of this specification for standard for each
signal type sent between routers.
Connector: 24, BNC, loop-thru
Impedance: 75
Ω
Signal Details: See related section of this specification for details for each
signal type, I/O levels and return loss.
