32 Rev 1.3 • 10 Oct 08
2. Installation
Package Contents
Package Contents
When your NV7512 products from NVISION arrive, immediately inspect the shipping container
for any obvious damage. If the container is damaged, unpack and inspect the contents. If the con-
tents are damaged, notify the carrier immediately.
When unpacking the shipping container, look for the packing slip and compare it against the con-
tents to verify that everything ordered was received. If anything is missing (or if equipment is dam-
aged unrelated to shipping), please contact NVISION.
The package does not contain mounting rack, network cables, video cables, mounting screws, or
grounding wire.
This document does not address the shipment or installation of any other equipment or software
that can be used in conjunction with the routers, including router control systems or configuration
software.
Preparing for Installation
You will need the following items before getting started:
Note The NV7512 has a separate power supply frame (NV6257).
A PC running Windows
®
2000 or higher, or Windows XP Professional. ® This PC is
required only for system configuration.
PC hardware requirements:
CD drive
EIA-232 serial COM port (DE9) capable of operating at 38.4 kb/s.
10BaseT or 10/100BaseT (preferred) Ethernet port.
100 MB/s Ethernet switch with at least 4 ports.
RJ-45 connectors and Ethernet cables (category 5).
DE9 connectors EIA-232 serial cable.
DIN 1.0/2.3 connectors and 1855A Belden cables; tool for connecting DIN connec-
tors.
75 Ω connectors and 1694A Belden cables (for frame expansion).
75 Ω BNC connectors and coaxial cables.
50 Ω BNC connectors and coaxial cables.
Reference audio and video source at the line rate appropriate for your system.
Frame rack suitable for mounting the router and NV6257 power supply.
