14 Rev 1.3 • 10 Oct 08
1. Introduction
Module Slots and Rear Connectors
manages the signal mixing performed by the Quad Mix card and is required if the Quad Mix back-
plane and Quad Mix output card are installed. For more information about the Quad Mix card, see
Quad Mix on page 28. There is no corresponding input backplane or input card. For more informa-
tion on connecting to the NV9660, see NVISION’s NV9660 Quad Mix Control Panel on page 98.
Monitor Backplane
The monitor backplane features four BNC connectors that distribute outgoing signals for monitor-
ing purposes. Each BNC connector can be connected to external monitoring equipment so that the
quality of outgoing signals can be verified. The monitor backplane has a corresponding monitor
card and is installed in a unique backplane slot in the back plate. There is no corresponding input
backplane or input card. For more information, see
Installing Backplanes on page 41 and Monitor
Card on page 29.
Backplane Types and Signals
The following is a list of each backplane type, associated connectors, signal types managed, and the
number of signals each backplane can receive or distribute. For your convenience, the part number
for each backplane is included.
Type of Signals
Managed Backplane
Name Connector
Type(s)
Connectors
per
Backplane
Signals
Managed
Part
Number
(Input) Part
Number
(Output)
AES unbalanced,
synchronous AES DIN 1.0/2.3 32 32 stereo
64 mono EM0486 EM0485
AES balanced,
synchronous
AES DB25 4 16 stereo
32 mono
EM0490 EM0491
Analog Analog DB25 4 16 stereo
32 mono EM0420 EM0421
MADI unbalanced,
synchronous
Note: 2 connectors
support 2 signal
streams; 2
connectors support
optional MADI
references (see
MADI Reference
on page 67).
MADI BNC 4 64 mono EM0492 EM0493
AES unbalanced and
Analog
(Ethernet connection
to Quad Mix control
panel, NV9660) Quad Mix
(output only) BNC
Ethernet
DB25 4 BNC
1 Ethernet
1 DB25
AES
balanced:
4 stereo
Analog:
4 stereo or
8 mono
N/A EM0512
Forwards outgoing
signals to monitor
equipment (see
Monitor Card on
page 29).
Monitor BNC 4 1 output from
each output
card
N/A EM0429
