Yaskawa CM012 DeviceNet Option Card - Manual (Page 47)

Supported Objects 2-26
‹
Class 108 (6Ch) - Yaskawa Option Parameter Object
Option Object – Class 108 (6Ch) Instance 1
Attr
G5M F7U G7U P7U
Prm Text Prm Text Prm Text Prm Text
1 F1-01 PG Pulses/Rev F1-01 PG Pulses/Rev F1-01 PG Pulses/Rev
2 F1-02 PG Fdbk Loss Select F1-02 PG Fdbk Loss Select F1-02 PG Fdbk Loss Select
3 F1-03 PG OverSpd Select F1-03 PG OverSpd Select F1-03 PG OverSpd Select
4 F1-04 PG Deviation Select F1-04 PG Deviation Select F1-04 PG Deviation Select
5 F1-05 PG Rotation Select F1-05 PG Rotation Select F1-05 PG Rotation Select
6 F1-06 PG Output Ratio F1-06 PG Output Ratio F1-06 PG Output Ratio
7 F1-07 PG Ramp PI/I Select F1-07 PG Ramp PI/I Select F1-07 PG Ramp PI/I Select
8 F1-08 PG OverSpd Lvl (%) F1-08 PG OverSpd Lvl (%) F1-08 PG OverSpd Lvl (%)
9 F1-09 PG OverSpd (s) F1-09 PG OverSpd (s) F1-09 PG OverSpd (s)
10 (Ah) F1-10 PG Deviate Lvl (%) F1-10 PG Deviate Lvl (%) F1-10 PG Deviate Lvl (%)
11 (Bh) F1-11 PG Deviate Time (s) F1-11 PG Deviate Time (s) F1-11 PG Deviate Time (s)
12 (Ch) F1-12 PG # Gear Teeth F1-12 PG # Gear Teeth F1-12 PG # Gear Teeth
13 (Dh) F1-13 PG # Gear Teeth 2 F1-13 PG # Gear Teeth 2 F1-13 PG # Gear Teeth 2
14 (Eh) F2-01 AI-14 Input Select F1-14 PG Open Detect F1-14 PG Open Detect
15 (Fh) F3-01 DI Input Select F1-15 Spd Detect Filter F1-15 Spd Detect Filter
16 (10h) F4-01 AO Ch1 Select F2-01 AI-14 Input Select F2-01 AI-14 Input Select
17 (11h) F4-02 AO Ch1 Gain (%) F3-01 DI Input Select F3-01 DI Input Select
18 (12h) F4-03 AO Ch2 Select F4-01 AO Ch1 Select F4-01 AO Ch1 Select
19 (13h) F4-04 AO Ch2 Gain (%) F4-02 AO Ch1 Gain (%) F4-02 AO Ch1 Gain (%)
20 (14h) F5-01 DO Ch1 Select F4-03 AO Ch2 Select F4-03 AO Ch2 Select
21 (15h) F5-02 DO Ch2 Select F4-04 AO Ch2 Gain (%) F4-04 AO Ch2 Gain (%)
22 (16h) F6-01 DO-08 Select F4-05 AO Ch1 Bias (%) F4-05 AO Ch1 Bias (%)
23 (17h) F7-01 PO-36F Select F4-06 AO Ch2 Bias (%) F4-06 AO Ch2 Bias (%)
24 (18h) F1-14 PG Open Detect Time F4-07 AO Ch1 Output Lvl F4-07 AO Ch1 Output Lvl
25 (19h) F8-01 E-15 Detect Select F4-08 AO Ch2 Output Lvl F4-08 AO Ch2 Output Lvl
26 (1Ah) F9-01 EF0 Fault Select F5-01 DO Ch1 Select F5-01 DO Ch1 Select
27 (1Bh) F9-02 EF0 Fault Detect F5-02 DO Ch2 Select F5-02 DO Ch2 Select
28 (1Ch) F9-03 EF0 Select F5-03 DO Ch3 Select F5-03 DO Ch3 Select
29 (1Dh) F9-04 Trace Sample Time F5-04 DO Ch4 Select F5-04 DO Ch4 Select
30 (1Eh) F1-15 Spd Detect Filter Select F5-05 DO Ch5 Select F5-05 DO Ch5 Select
31 (1Fh) F9-05 Torq Ref/Limit Select F5-06 DO Ch6 Select F5-06 DO Ch6 Select
32 (20h) F9-06 Com BUS Fault Select F5-07 DO Ch7 Select F5-07 DO Ch7 Select
33 (21h) F4-05 AO Ch1 Bias F5-08 DO Ch8 Select F5-08 DO Ch8 Select
34 (22h) F4-06 AO Ch2 Bias F5-09 DO Ch8 Mode Select F5-09 DO Ch8 Mode Select
35 (23h) F6-01 Com BUS Fault Select F6-01 Com BUS Fault Select
36 (24h) F6-02 EF0 Detect F6-02 EF0 Detect
37 (25h) F6-03 EF0 Fault Select F6-03 EF0 Fault Select
38 (26h) F6-04 Trace Sample Time F6-04 Trace Sample Time
39 (27h) F6-05 Current Units Select F6-05 Current Units Select
40(28h) F6-06 Torq Ref/Limit Select F6-06 Torq Ref/Limit Select
41 (29h)
Reserved ...
48 (30h)
49 (31h) F1-21 PG Pulses/Rev 2
50 (32h) F1-22 PG Rotation Select 2
51 (33h) F1-23 PG Gear Teeth Count 1
