Parameters A - 21

Ref Detection

L4-01

Speed Agreement Detection Level
Spd Agree Level

L4-01 and L4-02 are used in conjunction with the
multi-function outputs, (H2-01and H2-02) as a setpoint
and hysteresis for a contact closure.

0.0 to 200.0

0.0Hz

Programming

L4-02

Speed Agreement Detection Width
Spd Agree Width

0.0 to 20.0

2.0Hz

Programming

L4-05

Frequency Reference Loss
Detection Selection
Ref Loss Sel

Determines how the drive will react when the frequency
reference is lost.
0: Stop (Disabled) - Drive will not run at the frequency

reference

1: Enabled @ % of PrevRef - Drive will run at a

percentage (L4-06) of the frequency reference level
at the time frequency reference was lost.

0 or 1

1

Programming

L4-06

Frequency Reference Level at
Loss Frequency
Fref at Floss

If Frequency Reference loss function is enabled
(L4-05=1) and Frequency Reference is lost, then the
drive will run at reduced frequency reference deter-
mined by L4-06. New Fref =Fref at time of loss x L4-06.

0 to 100.0%

80.0%

Programming

Fault Restart

L5-01

Number of Auto Restart Attempts
Num of Restarts

Determines the number of times the drive will perform
an automatic restart.

0 to 10

0

Quick Setting

L5-02

Auto Restart Operation Selection
Restart Sel

Determines if the fault contact activates during an
automatic restart attempt.
0: No Flt Relay - fault contact will not activate during

an automatic restart.

1: Flt Relay Active - fault contact will activate during

an automatic restart.

0 or 1

0

Programming

L5-03

Maximum Restart Time After
Fault
Max Restart Time

If the restart fails (or is not attempted due to a
continuing fault condition, e.g. an OV fault) the Drive
waits L5-03 seconds before attempting another restart.

0.5 to 600.0

180.0sec

Quick Setting

Torque Detection

L6-01

Torque Detection Selection 1
Load Detection

Determines the drive's response to an overtorque /
undertorque condition. Overtorque and Undertorque are
determined by the settings in parameters L6-02 and
L6-03.
0: Disabled
1: OL@SpdAgree - Alm (Overtorque Detection only

active during Speed Agree and Operation continues
after detection).

2: OL At RUN - Alm (Overtorque Detection is always

active and operation continues after detection)

3: OL@SpdAgree - Flt (Overtorque Detection only

active during Speed Agree and drive output will shut
down on an OL3 fault).

4: OL At RUN - Flt (Overtorque Detection is always

active and drive output will shut down on an OL3
fault.)

5: LL@SpdAgree - Alm (Undertorque Detection is

only active during Speed Agree and operation contin-
ues after detection).

6: LL at RUN - Alm (Undertorque Detection is always

active and operation continues after detection)

7: LL @ SpdAgree - Flt (Undertorque Detection only

active during Speed Agree and drive output will shut
down on an OL3 fault).

8: LL At RUN - Flt (Undertorque Detection is always

active and drive output will shut down on an OL3
fault).

0 to 8

0

Programming

L6-02

Torque Detection Level 1
Load Det Lvl

Sets the overtorque/undertorque detection level as a
percentage of Drive rated current.

0 to 300

15%

Programming

L6-03

Torque Detection Time 1
Loss Det Time

Sets the length of time an overtorque / undertorque
condition must exist before being recognized by the
drive. OL3 is then displayed.

0.0 to 10.0

10.0sec

Programming

Table A.1

Parameter List (Continued

)

Parameter

No.

Parameter Name

Digital Operator Display

Description

Setting

Range

Factory

Setting

Menu

Location
