Electrical Installation 2 - 14

Control Circuit Terminal Functions

The factory default functions of the control circuit terminals for 2-wire control are shown in Table 2.8.

Table 2.8 Control Circuit Terminals

Type

No.

Signal Name

Description

Signal Level

Digital

input

signals

S1

Forward run/stop command

Forward run when CLOSED; stopped when OPEN.

24 Vdc, 8 mA

Photocoupler isolation

S2

Reverse run/stop command

Reverse run when CLOSED; stopped when OPEN.

S3

External fault input

Fault when CLOSED.

Multi-function

digital inputs

Functions set by

H1-01 to H1-05.

S4

Fault reset

Reset when CLOSED

S5

Multi-step speed reference 1

(Master/auxiliary switch)

Auxiliary frequency reference

when CLOSED.

S6

Multi-step speed reference 2

Multi-step setting 2 when

CLOSED.

S7

Jog frequency reference

Jog frequency when CLOSED.

SN

Digital input common

Refer to Table 2.10 for connection details.

SC

SP

Analog

input

signals

+V

+15Vdc power supply

+15Vdc power supply for analog inputs or transmitters

+15Vdc

(Max. current: 20 mA)

A1

Analog input or

Speed Command

0 to +10Vdc/100%

0 to +10 V(20 k

Ω)

A2

Multi-function analog input

4 to 20 mA/100%

0 to +10Vdc/100% (H3-0

Function set by

H3-09.

4 to 20 mA(250

Ω)

0 to +10 V(20k

Ω)

AC

Analog common

E(G)

Shield wire, optional ground

line connection point

Digital

output

signals

M1

During Run

(N.O. contact)

CLOSED during operation

Multi-function

digital output

Function set by

H2-01.

Dry contacts

Contact capacity:

1 A max. at 250Vac

1 A max. at 30Vdc

M2

M3

Remote/Auto Operation

(N.O. contact)

CLOSED when local control

Multi-function

digital output

Function set by

H2-02.

M4

MA

Fault output signal

(SPDT)

MA/MC: CLOSED during fault condition

MB/MC: OPEN during fault condition

Dry contacts

Contact capacity:

1 A max. at 250Vac

1 A max. at 30Vdc

MB
MC

Analog

output

signals

FM

Multi-function analog output

(output frequency)

0 to +10Vdc/100% frequency

Multi-function

analog monitor 1

Function set by

H4-01

0 to +10Vdc max. ±5%

2 mA max.

AC

Analog common

AM

Multi-function analog output

(output current)

0 to +10Vdc/100% Drive's rated

output current

Multi-function

analog monitor 2

Function set by

H4-04

RS-485/

422

R+

Modbus

communication input

For 2-wire RS-485, jumper R+ and S+ and

jumper R- and S-.

Differential input,

PHC isolation

R-

S+

Modbus

communication output

Differential input,

PHC isolation

S-

IG

Signal common

-

-
