NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) - Manual (Page 264)

4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > Multicast > IGMP Snooping > Multicast Router VLAN
Configuration.
The Multicast Router VLAN Configuration page displays.
6. From the Interface menu, select the interface.
7. In the VLAN ID field, enter the VLAN ID.
8. From the Multicast Router menu, select Enable or Disable to specify if the VLAN
is a multicast router VLAN.
9. Click the Apply button.
Your settings are saved.
10. To save the settings to the running configuration, click the Save icon.
IGMP snooping querier overview
IGMP snooping requires that one central switch or router periodically query all
end-devices on the network to announce their multicast memberships. This central
device is the IGMP querier. The IGMP query responses, known as IGMP reports, keep
the switch updated with the current multicast group membership on a port-by-port
basis. If the switch does not receive updated membership information in a timely fashion,
it stops forwarding multicasts to the port where the end device is located.
You can configure and display information for IGMP snooping queriers on the network
and, separately, on VLANs.
Configure the IGMP snooping querier global settings
You can configure the global settings for an IGMP snooping querier on the switch.
To configure the global settings for an IGMP snooping querier:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
Main User Manual 264 Configure Switching Information
AV Line of Fully Managed Switches M4250 Series Main User Manual
