10. If you select None from the IP Address Configuration Method menu, do the
following:
a. In the IP Address field, enter the IP address for the interface.
b. In the Subnet Mask, enter the subnet mask for the interface.
This is also referred to as the subnet/network mask, and defines the portion of
the interface’s IP address that is used to identify the attached network.
11. From the Routing Mode menu, select Enable or Disable to enable or disable the
routing mode for the interface.
The default is Enable.
12. From the Administrative Mode menu, select Enable or Disable to enable or disable
the administrative mode of the interface.
The default is Enable.
13. From the Forward Net Directed Broadcasts menu, select Enable or Disable to
enable or disable the forwarding of network-directed broadcast packets.
The default is Disable, which means that network-directed broadcast packets are
not forwarded but dropped.
14. From the Encapsulation Type menu, select the link layer encapsulation type for
packets transmitted from the specified interface.
You can select Ethernet or SNAP, which is Subnetwork Access Protocol. The default
is Ethernet.
15. From the Proxy Arp menu, select Enable or Disable to enable or disable the proxy
ARP for the interface.
The default is Enable.
16. From the Local Proxy Arp menu, select Enable or Disable to enable or disable the
local proxy ARP for the interface.
The default is Disable.
17. In the Bandwidth (kbps) field, specify the bandwidth for the interface.
This information in this field determines the speed of the interface to higher level
protocols. Some protocols use bandwidth to compute the link cost. The range is
from 1 to 10000000.
18. Form the ICMP Destination Unreachables menu, select Enable or Disable to enable
or disable the interface from sending ICMP destination unreachables messages.
The default is Enable.
