Screens on the Touch Panel (iX1500)
The screens displayed on the touch panel of the ScanSnap are either the home screen to start
scanning or the [Settings] screen to check or modify the settings of the ScanSnap.
This section explains the following screens:
l "Home screen" (page 103)
l "[Settings] Screen" (page 105)
Home screen
The home screen is a screen where you perform a scan.
2
1
3
Header (1)
Displays the connection statuses of the ScanSnap.
Displays the signal status between a wireless access point and the ScanSnap in four levels.
When the ScanSnap is searching for a wireless access point or is not connected to a wireless
access point, appears.
Appears when the ScanSnap and the computer are connected via a USB cable.
Appears when the ScanSnap and the computer or mobile device are connected directly via
wireless LAN.
Status (2)
Displays the connection status of a computer or mobile device that is occupying the ScanSnap.
Screens and Operations on the Touch Panel (iX1500)
103
