Attaching the Receipt Guide (iX1500)
When you scan business cards or receipts, attaching the Receipt Guide to the ScanSnap makes it
easy to scan them. By using the Receipt Guide for business cards and receipts, you can place
documents with different widths such as receipts in it to scan them at the same time.
Documents that can be scanned with the Receipt Guide
The Receipt Guide allows you to load three kinds of documents. It allows you to load different-sized
documents in each loading section to scan them at the same time.
In addition, you can move side guides, or close the ADF paper chute (cover) to turn the power off
with the Receipt Guide attached to the ScanSnap. Therefore, you do not need to attach and remove
the Receipt Guide every time you use it.
HINT
Attaching the Receipt Guide on the ScanSnap limits the number of sheets that can be loaded in the
ADF paper chute (cover). Remove the Receipt Guide from the ScanSnap when scanning a large
number of documents.
1
2
3
Loading
section 1 2 3
Document type Business cards and receipts Receipts Office paper
Paper weight 40 to 209 g/m 2 (11 to 56 lb)
Paper size
Width
58 mm (2.28 in.)
Length
50.8 to 360 mm (2 to 14.17 in.)
For long page documents, up
to 863 mm (34 in.)
Width
83 mm (3.26 in.)
Length
50.8 to 360 mm (2 to 14.17 in.)
For long page documents, up
to 863 mm (34 in.)
Width
148 to 216 mm (5.82 to 8.5 in.)
Length
50.8 to 360 mm (2 to 14.17 in.)
For long page documents, up
to 863 mm (34 in.)
1.
Open the ADF paper chute (cover) of the ScanSnap to turn the power on.
Attaching the Receipt Guide (iX1500)
