Fujitsu Ricoh Fujitsu ScanSnap iX1400 Document Scanner - Manual (Page 488)

Specifications of iX1500
The following table summarizes the specifications of the ScanSnap.
Item Specification
Product name ScanSnap iX1500
Scanning method Automatic Document Feeder (ADF), simultaneous duplex scanning
Scanning color mode Simplex/duplex, color/gray/black and white/auto (automatic color,
gray, and B&W detection)
Optical system/image sensor Equal-magnification optics/color CIS × 2 (front × 1, back × 1)
Light source 3 color LED (Red/Green/Blue)
Touch Panel 4.3 inch color display (pressure-sensitive touch panel)
Scanning speed (A4 portrait)
Automatic resolution/normal/better/best
30 sheets/minute
Excellent
8 sheets/minute
Scan area Refer to "Documents to Scan (iX1500)" (page 171)
Document thickness
Number of sheets allowed to be loaded Up to 50 sheets
A4: 80 g/m
2 (20 lb)
Interface USB USB 3.1 Gen 1 (*1)/USB 3.0 (*1)/USB 2.0/USB 1.1 (connector: B
type)
Wireless LAN (*2) IEEE802.11 a/b/g/n/ac (2.4 GHz/5 GHz) (*3)
Input power Voltage 100 to 240 V ±10%
Phase Single phase
Frequency range 50/60 Hz
Power consumption USB connection During operation: 17 W or less
During sleep mode: 1.5 W or less
Wireless LAN
connection During operation: 17 W or less
During sleep mode: 1.6 W or less
Temperature/humidity
allowable ranges Temperature During operation: 5 to 35 degrees C/41 to 95 degrees F
During standby: -20 to 60 degrees C/-4 to 140 degrees F
During storage/transportation: -20 to 60 degrees C/-4 to 140 degrees
F
Humidity During operation: 20 to 80%
During standby: 8 to 95%
During storage/transportation: 8 to 95%
Outer dimensions (Width × Depth × Height) Min.: 292 Ч 161 Ч 152 mm/11.50 Ч 6.34 Ч 5.98 in. (when the ADF
paper chute (cover) is closed)
Max.: 292 Ч 494 Ч 293 mm/11.50 Ч 19.45 Ч 11.54 in. (when the ADF
paper chute (cover) is open and the extension is extended)
Weight 3.4 kg (approx. 7.50 lb)
Environmental specification Compliant with the International Energy Star Program, and RoHS
Directive
Specifications of the ScanSnap
488
