Filling in Fingers Captured in a Scanned Image (When a
Document Is Scanned)(SV600)
Fingers that are captured when a document is scanned can be filled in.
ATTENTION
l
Do not hold the corners of the document when you scan.
If you do so, the shape of the image may not be recognized correctly.
l
To fill in fingers captured in the scanned image, the fingers need to be detected.
If a document is scanned in the following ways, captured fingers may not be detected correctly.
-
When two or more fingers that are used to hold down a document to be scanned are touching
each other (Figure 1)
-
When you hold down a document to be scanned with manicured fingers or fingers with artificial
nails (Figure 2)
-
When you hold down a document to be scanned with your fingers bent (Figure 3)
-
When fingers that are used to hold down a document to be scanned are captured 1 cm (0.39
in.) or more (Figure 4)
-
When there is text or an image within 5 mm (0.2 in.) around the fingers that are used to hold
down a document to be scanned (Figure 5)
-
When a document that has a background color other than white is scanned (Figure 6)
-
When a document is scanned after [Gray], [B&W], or [Color high compression] is selected from
the [Color mode] drop-down list in the [Scanning] tab of the
1 cm (0.39 in.)
5 mm (0.2 in.)
1
2
3
4
5
6
or More
or Less
HINT
l
Up to five fingers on each side (top/bottom/right/left) of the document can be filled in.
l
To prevent image deterioration, select and fill in as many fingers as possible in one go.
When a Document Is Scanned (SV600)
