Side Guide
ATTENTION
l Do not accumulate more than 50 sheets (with paper weight of 80 g/m 2 [20 lb]) in the stacker.
l When the [Place document face up] checkbox is selected in the [Scanning mode option]
window, load the documents face-up and bottom edge down.
To open the [Scanning mode option] window, click the [Option] button in the [Scanning] tab of
the
"ScanSnap Setup Window" (page 88) .
7.
Adjust the side guides to the width of the documents.
Hold each side guide in the middle to adjust them. Otherwise, the documents may be fed
skewed.
Documents
8.
Press the [Scan] button in the home screen on the touch panel to start
scanning the documents.
Scanning Documents with iX1500
177
