Specifications of iX100
The following table summarizes the specifications of the ScanSnap.
Item Specification
Product name ScanSnap iX100
Scanning method Manual feed (Continuous Document Feeding (CDF) function
supported), simplex scanning, two selectable paper paths (U-turn
path (*1), straight path (*2))
Scanning color mode Simplex, color/gray/black and white/auto (automatic color, gray, and
B&W detection)
Optical system/image sensor Equal-magnification optics/color CIS × 1
Light source 3 color LED (Red/Green/Blue)
Scanning speed (A4 portrait)
Automatic resolution/normal/better/best
5.2 sec/sheet
Excellent
20.4 sec/sheet
Scan area Refer to "Documents to Scan (iX100)" (page 230)
Document thickness
Interface USB USB 2.0/USB 1.1 (connector: USB Micro-B type) (*3)
Wireless LAN (*4) IEEE802.11b/g/n compliant
Input power Voltage 5 V (USB bus power)
Power consumption During operation: 4.7 W or less
During sleep mode: 2.2 W or less
Temperature/humidity
allowable ranges Temperature During operation: 5 to 35 degrees C/41 to 95 degrees F
During standby: -20 to 60 degrees C/-4 to 140 degrees F
During storage/transportation: -20 to 60 degrees C/-4 to 140 degrees
F
Humidity During operation: 20 to 80%
During standby: 8 to 95%
During storage/transportation: 8 to 95%
Outer dimensions (Width × Depth × Height) Min.: 273 Ч 47.5 Ч 36 mm/10.75 Ч 1.87 Ч 1.42 in. (when the feed
guide and output guide are closed)
Max.: 273 Ч 80 Ч 59 mm/10.75 Ч 3.15 Ч 2.32 in. (when the feed
guide and output guide are open)
Weight 400 g (approx. 0.88 lb)
Environmental specification Compliant with the International Energy Star Program, and RoHS
Directive
Specifications of the ScanSnap
492
