Page 186
2. Load the documents at the center of the ADF paper chute (cover).
ATTENTION
l
Load all documents over one another above the pick roller (center). Documents that are not
loaded above the pick roller cannot be fed.
Incorrect
Pick Roller's Width
l
Adjust the side guides to the widest document. If the side guides are not adjusted properly, a
paper jam may occur.
l
Load smaller documents so that they can be scanned straight.
If the documents are skewed during scanning, the following problems may occur:
-
Part of the document does not appear in the scanned image
-
Slant lines appear in the scanned image
-
The documents are scanned in a wrong paper size
If the documents are not scanned straight, it is recommended that you select the [Continue
scanning after last page] checkbox in the [Scanning] tab of the
, separate the documents by their widths, and scan them in different batches.
Scanning Documents with iX1500
186
