Specifications of SV600
The following table summarizes the specifications of the ScanSnap.
Item Specification
Product name ScanSnap SV600
Scanning method Overhead scanning
Scanning color mode Color/gray/black and white/auto (automatic color, gray, and B&W
detection)
Optical system/image sensor Lens reduction optics/color CCD × 1
Light source (White LED + lens illumination) × 2
Scanning speed (A3 landscape) 3 sec/sheet
Scan area Automatic detection (maximum), automatic detection (A4 landscape/
letter landscape), A3 landscape, A4 landscape, A5 landscape, A6
landscape, B4 landscape, B5 landscape, B6 landscape, Post card
landscape, Business card, Letter landscape, Legal landscape, 11 ×
17 in. landscape, custom size (maximum: 432 × 300 mm/17.01 ×
11.81 in., minimum: 25.4 × 25.4 mm/1.00 × 1.00 in.)
Magnification in vertical scanning (length) ±1.5%
Document thickness 30 mm (1.18 in.) or less
Interface USB 2.0/USB 1.1 (connector: B type) (*1)
Input power Voltage 100 to 240 V ±10%
Phase Single phase
Frequency range 50/60 Hz
Power consumption During operation: 20 W or less
During sleep mode: 2.6 W or less
Temperature/humidity
allowable ranges Temperature During operation: 5 to 35 degrees C/41 to 95 degrees F
During standby: -20 to 60 degrees C/-4 to 140 degrees F
During storage/transportation: -20 to 60 degrees C/-4 to 140 degrees
F
Humidity During operation: 20 to 80%
During standby: 8 to 95%
During storage/transportation: 8 to 95%
Outer dimensions (Width × Depth × Height) 210 Ч 156 Ч 383 mm/8.27 Ч 6.14 Ч 15.08 in.
Weight 3.0 kg (approx. 6.62 lb)
Environmental specification Compliant with the International Energy Star Program, and RoHS
Directive
Specifications of the ScanSnap
494
