Initial Device Set-Up Using the Vaddio Device Controller
The Vaddio Device Controller is a stand-alone tablet for working with Vaddio products' web interfaces.
To complete the initial device set-up with the Vaddio Device Controller:
1. Connect the touch-panel to the network on the same subnet as the products you need to work with –
for example, connect both to the same PoE+ switch.
2. Go to the touch-panel's Configuration page (gear icon) and select Scan.
3. Locate the device you need to work with, and select Use.
4. Select Exit to leave the Configuration page and open the device's web interface.
Note
The first time you access a device at a specific IP address, the Vaddio Device Controller's screen
may remain blank for 20 seconds or more.
5. Set the admin password. This logs you in.
If the Vaddio Device Controller does not find the device, verify that the Vaddio Device Controller and the
device are connected to the same subnet. You may need to
access the web interface manually
Initial Device Set-Up Using the Vaddio Deployment Tool
Be sure you have the current version of the Vaddio Deployment Tool. If you have a copy of the tool
already, compare its version information to the version shown on the release notes. You can find both at
under the
Resources tab.
To complete the initial device set-up with the Vaddio Deployment Tool:
1. Download and install the Vaddio Deployment Tool if you have not done so already, then open it.
2. Power up the OneLINK device if you have not done so already.
3. On the Find Devices page, click Scan. If the scan does not locate the device, your computer may be
on a different subnet. Click Advanced and specify the appropriate portion of the network to scan.
4. In the list of equipment that the scan discovers, locate the devices marked Not Set Up.
5. For each device that you need to work with, click the Not Set Up button and set the admin password
on the device detail page that opens. Other people using the Vaddio Deployment Tool then have the
option to log in, as shown for the other devices in the screen shot.
You can use the Vaddio Deployment Tool to access the web interface of any device in the device list, if it
is set up and you have provided the admin password.
If the Vaddio Deployment Tool cannot discover the OneLINK device, you may need to
.
