212
Setting Up Rooms
Managing Rooms
2 Expand the filtered System list in the Tools pane, and then drag the appropriate output
head onto a display in the Rooms tab.
The name of the output head is indicated on the display. In the case of a
Kaleido-X (4RU) or Kaleido-X (7RU), the card slot is also indicated. In the case of a cluster
system, the name of the originating multiviewer also appears.
Note:
All currently open display libraries appear on the Tools pane. Custom
display libraries are stored separately from the XEdit workspace.
See
on page 227 for details.
Filtered
Display
Room
Selected
selected display
System list
library
area
display
Properties of the
