Select here uncheck this – Cobalt Co9992-4ENC-4K-HEVC Software-Defined Broadcast Encoder User Manual
Page 107
107
Config Save Button:
If you click on this button, the current card configuration is saved
on the corresponding slot, possibly replacing the configuration saved there if it is not
empty.
Download Config:
If you click on the
Save
button, the corresponding file is downloaded
to your computer. This feature is provided to allow configuration backups.
If you save a configuration to your computer, and later wish to restore it to the 9992-ENC, use
the following procedure:
1.
On Dashboard™, open the user interface for the frame controller (slot 0).
2.
Select the
Data Safe
tab in the configuration area.
3.
Uncheck the
Disable
checkbox corresponding to the card you wish to restore the
configuration. This step is depicted below.
4.
On the Dashboard™ Tree View, right-click on the card, and select
Restore
Configuration.
Follow the prompts and navigate to the file you wish to restore. This
process is illustrated below
Select here
Uncheck this
