Zilog Z86193 User Manual
Page 209
Z8
®
CPU
User Manual
UM001604-0108
Instruction Description
202
LDEI @R2, @RR6
Op Code: 83 26
loads the value
C3h
into Register
23h
. Working Register Pair RR6 is incremented to
404Ch
and Working Register R2 is incremented to
24h
.
Example 2
If Working Register R2 contains
22h
, Register
22h
contains
ABh
, Register
23h
contains
C3h
, and Working Register Pair R6 and R7 contains
404Ah
, the statement:
LDEI @RR6, @R2
Op Code: 93 26
loads the value
ABh
into external data memory location
404Ah
. Working Register R2 is
incremented to
23h
and Working Register Pair RR6 is incremented to
404Bh
. A second
LDEI @RR6, @R2
Op Code: 93 26
loads the value
C3h
into external data memory location
404Bh
. Working Register R2 is
incremented to
24h
and Working Register Pair RR6 is incremented to
404Ch
.
This instruction format is valid only for MCUs which can address external data memory.
Note:
