Installation
ATTENTION
Installation should be performed by qualified service personnel only in
accordance with the National Electrical Code or applicable local codes.
Mounting
1. Unlock the front door of the enclosure using a screwdriver by rotating the lock a quarter turn
counterclockwise, and open the front door.
2. Install the external mounting feet supplied with the enclosure prior to mounting the line extender to the
wall or other mounting surface. To ensure proper sealing and enclosure protection rating, use the
provided sealing washers. Install the sealing washers inside the enclosure with the tapered cone
against the enclosure and then add the flat washers.
N OTE : If removing rear component panel to install the mounting feet, disconnect the ribbon cables and
the ground wire connections from the rear panel. Remove the four nuts that hold the panel in place, and
set the panel assembly and the nuts aside in a safe location. Reinstall panel after the mounting feet are
bolted to the enclosure.
3. Position the enclosure on the mounting surface and secure it with four 3/8-inch diameter bolts of the
appropriate lengths for the mounting surface. See Figure 2 on page 2 for enclosure and mounting
dimensions.
4. Drill or punch cable entries into the cabinet at the required locations. If installing the LE300-IP Line
Extender outdoors or in an uncontrolled temperature/humidity area, bottom conduit/cable entry is
recommended. Use conduit hubs or cable glands equipped with an O-ring to prevent entry of dust or
moisture which can damage the internal components.
5. Pull the cables into the enclosure, and make connections per the wiring section of this manual.
6. Complete the installation by closing the front door and locking the enclosure.
