Terminal Designator Description
TB3 (Top)
N.C.
Output 3 – contact #1 COM
N.O.
TB3 (Bottom)
N.C.
Output 3 – contact #2 COM
N.O.
TB4 (Top)
N.C.
Output 4 – contact #1 COM
N.O.
TB4 (Bottom)
N.C.
Output 4 – contact #2 COM
N.O.
TB5 (Top)
N.C.
Output 5 – contact #1 COM
N.O.
TB5 (Bottom)
N.C.
Output 5 – contact #2 COM
N.O.
TB6 (Top)
N.C.
Page Line Audio – contact #1 COM
N.O.
TB6 (Bottom)
N.C.
Page Line Audio – contact #2 COM
N.O.
TB7 (Top)
N.C.
Page Line Ground Fault – contact #1 COM
N.O.
TB7 (Bottom)
N.C.
Page Line Ground Fault – contact #2 COM
N.O.
